Product Overview
CM 2812 DEXTERITY is a 925KV cinematic-lifter motor listed for 6S propulsion. The 2812 motor uses a D33.6 × 44.8 mm body, 86.2 g motor weight and a published maximum thrust of 2920 gf. Confirm propeller, ESC, battery and frame clearance before ordering.
Technical Specifications
| Specification | Published value |
|---|---|
| Motor model | MAD DEXTERITY CM2812 V1.0 |
| KV / battery | 925KV / 5–6S LiPo |
| Number of pole pairs | 7 |
| Motor size | D33.6 × 44.8 mm |
| Stator core | High-quality silicon steel sheets; high-temperature coating resistant to 180°C |
| Varnished wire degree | 220°C |
| Magnet degree | 150°C |
| Propeller mounting | M5 nut |
| Motor mounting | D19 M3×4 |
| Shaft diameter | 5 mm |
| Cable | 250 mm 18# AWG red/black silicone |
| Bearing | 685×2 |
| Maximum current | 49.3 A |
| Maximum power | 1125.9 W |
| Rated output power | 145 W |
| Maximum thrust | 2920 gf |
| Motor weight | 86.2 g |
| Internal resistance | 41.5 mΩ |
| Disruptive test | 500 V |
Selection and Compatibility
Match the 925KV option and 5–6S battery with the selected propeller and ESC. Confirm the 5 mm shaft, M5 propeller interface and D19 M3×4 motor mounting before ordering.
FAQ
What should be confirmed for a quote?
Provide the aircraft platform, battery, propeller, ESC, mounting pattern and required quantity so the CM2812 configuration can be reviewed.
Request a Quote
Send the required configuration and application to ReachSky for a written B2B quotation.
